GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable

GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable
GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable
GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable

Large Image :  GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable

Product Details:
Place of Origin: China
Brand Name: OEM/ ODM/ YUEXIANKE
Certification: UL/ CE/ ETL/ ROHS/ ANATEL
Model Number: GYTXW
Payment & Shipping Terms:
Minimum Order Quantity: 1000 meters
Price: Negotiation
Packaging Details: 1000 Meters
Delivery Time: 3-7Work Day
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 100000 Meters/Day
Contact Now

GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable

Description
Model NO: GYTXW Strengthen Member:: Metallic
Cover Material:: PE Using:: Aerial
Loose Tube:: Uni-Tube Cable Water Blacking Tape:: Yes
Type:: Singlemode Fiber Count:: 2-144 Cores
High Light:

GYXTW Loose Tube Fiber Cable

,

G652D Loose Tube Fiber Cable

,

G652D fiber patch cables

GYXTW Fiber Cable Outdoor Loose Tube Fiber Optic Cable Manufacturer Gyxtw G652d Fiber



Features

1. Low dispersion and attenuation
2. Proper design, precise control for fiber excess length and distinct stranding process render the cable
3. excellent mechanical and environmental properties
4. Compact structure and lightness, flexible and good bend-resistant performance
5. With small cable diameter, light cable weight, self-supporting
6. Operating Temperature : -40 ~ +60 C

The tube color is nature. And fiber color in the tube starts from No. 1 Blue
No.
1
2
3
4
5
6
Color
Blue
Orange
Green
Brown
Gray
White
No.
7
8
9
10
11
12
Color
Red
Black
Yellow
Purple
Pink
Aqua
No.
13
14
15
16
17
18
Color
Blue S100
Orange S100
Green S100
Brown S100
Gray S100
White S100
No.
19
20
21
22
23
24
Color
Red S100
Nature S100
Yellow S100
Purple S100
Pink S100
Aqua S100
Product Paramenters
SN
Item
Unit
Value
1
No. of fibers
count
4/6
8/12
24
2
Tube diameter
count
2.2
2.4
3.2
3
Cable diameter(±5%)
mm
8.5
8.7
9.5
4
Cable weight(±10%)
kg/km
72
74
87
5
Short term tension
N
1500
6
Short term crush
N/100mm
1000

Characteristic of Optical Cable

1 Min. bending radius for installation
Static: 15 x cable diameter
Dynamic: 20 x cable diameter

2.Application temperature
range Operation: - 40℃ ~ +60℃
Installation: -10℃ ~ +60℃
Storage/transportation: - 40℃~ +60℃

3.Main mechanical & environmental performance test
Item
Test Method
Acceptance Condition
Tensile Strength IEC 60794-1-2-E1
- Load: Short term tension
- Length of cable: about 50m
- Load time: 1min
- Fiber strain £ 0.6%
- No fiber break and no sheath damage.
Crush Test
IEC 60794-1-2-E3
- Load: Short term crush
- Load time: 1min
- Loss change £ 0.1dB@1550nm
- No fiber break and no sheath damage.

Characteristic of Optical Fiber

G652D fiber information
Mode field diameter (1310nm): 9.2mm±0.4mm
Mode field diameter (1550nm): 10.4mm±0.8mm
Cut off wavelength of cabled fiber (lcc): £1260nm
Attenuation at 1310nm: £0.36dB/km
Attenuation at 1550nm: £0.22dB/km
Bending loss at 1550nm (100 turns, 30mm radius): £0.05dB Dispersion in the range 1288 to 1339nm: £3.5ps/ (nm•km)
Dispersion at 1550nm: £18ps/ (nm•km) Dispersion slope at zero dispersion wavelength: £0.092ps/ (nm2•km)



GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable 0GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable 1GYXTW G652D Outdoor Singlemode Loose Tube Fiber Cable 2

FAQ



1.What is your MOQ?

Could be coordinated if you have detail requirements.



2.How about your delivery date?
Delivery date is about 3-5days, it depends on the order quantity.

3.Can you supply sample for customers?
Of course, however the delivery cost will be charged on customer's account.

4.How about your price?
We are supplying products with very competitive price based on good performance.

5.Do you offer OEM Service?
We accept OEM, ODM. The cable size and material are customized. Our own logo and own design are welcome. We will produce according to your requirment and description.
