GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel

GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel
GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel
GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel

Large Image :  GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel

Product Details:
Place of Origin: China
Brand Name: OEM/ ODM/ YUEXIANKE
Certification: UL/ CE/ ETL/ ROHS/ ANATEL
Model Number: GYXTW
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Meters
Price: Negotiation
Packaging Details: 1000 Meters
Delivery Time: 7~15Work Day
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 100000 Meters/Day

GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel

Description
Fiber Count:: 2~288 Color:: Black
Fiber Type:: SM Single Mode/ MM Multi Mode Length:: 1000~4000m/Reel
Applicable Fibers:: Telecom Comunication Material Of Jacket: Black Polyethylene (PE)
Number Of Conductor:: ≥ 10 Use:: FTTX
High Light:

4000m/Reel Fiber Optic Cable

,

GJXFH Fiber Optic Cable

,

GJFJV Fiber Optic Cable

GYTXW/GYTC8S/GJFJV/GJXH/GJXFH/4/6/8/12/24/48/72/96/128/288 core fibar optica cable

Single mode or multimode fibres are position in a loose tube made of a high modulus plastic.The tube are filled with a water resistant filling compound.A steel wire,sometimes sheathed with ployethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member.

Tubes (and fillers) are stranded around the strength member into a compact and circular cable core.the cable core is filled with filling compound to protect it from water ingress,over which a thin PE inner sheath is applied.After the PSP is longitudinally applied overthe inner sheath, the cable is completed with a PE sheath.



Performance of Cabled Optical Fiber

The performance of cabled optical fiber (ITU-T Rec. G.652D)
Item
Specification

Fiber type
Single mode

Fiber material
Doped silica

Attenuation coefficient
@ 1310 nm
@ 1383 nm
@ 1550 nm
@ 1625 nm

≤ 0.36 dB/km
≤0.35 dB/km
≤0.22 dB/km
≤0.25 dB/km

Point discontinuity
≤ 0.05 dB

Cable cut-off wavelength
≤ 1260 nm

Zero-dispersion wavelength
1300 ~ 1324 nm

Zero-dispersion slope
≤0.092 ps/(nm².km)

Chromatic dispersion
@ 1288 ~ 1339 nm
@ 1271 ~ 1360 nm
@ 1550 nm
@ 1625 nm

≤3.5 ps/(nm. km)
≤5.3 ps/(nm. km)
≤18 ps/(nm. km)
≤22 ps/(nm. km)

PMD
≤0.2 ps/km½

Mode field diameter @ 1310 nm
(8.6~9.5)±0.6 um

Core / Clad concentricity error
≤0.6 um

Cladding diameter
125.0 ± 1 um

Cladding non-circularity
≤1.0%

Primary coating diameter
245 ± 10 um

Proof test level
100 kpsi (=0.69 Gpa), 1%

Temperature dependence
0℃~ +70℃ @ 1310 & 1550nm
≤ 0.1 dB/km


Cable bending radius: 10 x cable diameter (static)

20 x cable diameter (dynamic)
GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel 0
GYTC8S GJFJV GJXH GJXFH 128 Core Fiber Optic Cable 4000m/ Reel 1





Packing & Shipping

Cable Type Drum Length (KM) Drum/Carton size (cm) Gross weight/CTN (kgs) KMs/20ft
GYXTW 2~12F 2 70*70*60 160 144
