40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP

Certification
China Guangdong Jingchang Cable Industry Co., Ltd.  certification
China Guangdong Jingchang Cable Industry Co., Ltd.  certification
Customer Reviews
We're very Pleased to cooperate with you. Your good service makes me be satisfied! Will definitely be ordering more in the futher.

—— —— John Smith

Good quality Good Service! I am impressed. Keep cooperating!

—— —— Mohamed Rebai

I'm very pleased with the service of this company,I believe that their business will be better and better.

—— —— Ashot Matinyan

I'm Online Chat Now

40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP

40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP
40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP

Large Image :  40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP

Product Details:
Place of Origin: Guangdong, China
Brand Name: YUEXIANKE/OEM/ODM
Certification: Unilever/ROSH/CE/ANATEL/CPR/ETL
Model Number: CAT8
Payment & Shipping Terms:
Minimum Order Quantity: Stock as client's request, customized type 30000meter.
Price: Negotiation
Packaging Details: 305m/box,color box,reel or as customers' request
Delivery Time: 7-15 business days
Payment Terms: , T/T, MoneyGram
Supply Ability: 400000 Piece/Pieces per Month, sample is available

40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP

Description
Model Number:: CAT8-S/FTP Application:: Networking
Number Of Conductor:: 8 Jacket:: PVC, LSZH, PE Optional
Shield:: Foil& Braid Shielded Twisted Pair, U/FTP Packing:: 305m Easy Pull Box, Wooden/plastic/cardboard/empty Spool
Color:: White,black,gray,yellow,orange,purple, Customized Color Optional Conductor:: Pure Copper ( Oxygen-free Copper)
Core:: 4 Pairs 8 Core Flame Test Rated:: Plenum(CMP)/Riser(CMR)/Vertical Tray(CM)
High Light:

CAT7E Ethernet LAN Cable

,

2000Mhz Ethernet LAN Cable

40G High Speed 2000Mhz Double Shielded FTP CAT8 CAT7E Etherent Function Network Cable

High Quality Material
99.99% Bare Copper Core
Twist Pairs
Close pairs twisted to achieve low loss
Incredible Durability
Durable PVC/ LSZH jacket for maximum curve protection and long life cycle
Environment Jacket
New flexible enviroment PVC/LSZH jacket
Features
Precise triple-twist technology to achieve high transfer performance
Rated temperature over 75 °C
Minimum bending radius over 8D
RoHS/REACH Complied PVC, PE or LSZH Jacket
Reference Standard UL444
Fire resistance rate: CMP, CMR,CM optional
Complies to ANSI/TIA-568-C.2 &ISO/IEC 11801; EN50173&IEC61156-5

Application
Volp /ISDN/ Token
100Mbps TP-PDM
Analog and Data Video
TR-16 Active and Passive
155M/622M/1.2G ATM
IEEE 802.3-T: 10Base-T; 100Base-T; 1000Base-T;10GBase-T
ITEM
SSTP CAT8 ETHERNET CABLE
Conductor
Solid bare copper (OFC)
AWG
22AWG
Conductor Diameter(mm)
0.64±0.02
Insulation
Foam-skin PE
Insulation dimension(mm)
1.68±0.05
Jacket
PVC/LSZH
Sheath Average Thickness
0.75mm
Sheath Diameter
8.4±0.3mm
Individual shield & material
Alumimum foil (50/12um)
Overall shield & material
Tinned Copper
Shield coverage
Over 45% (16/6/0.1)
Drain wire
1/0.32 BC
Elongation after aging
Min.100%
Tensile Strength after aging
Above 8Mpa
Aging at 100℃ for 168Hrs
Min.elongation retention:50%;Min.tensile strength retention:75%
Rip cord
Including
Color Code
White/Blue;White/Orange;White/Green;White/Brown
Spark Test
1050 V ac
Dielectric Strength
2500 V dc/3 seconds
Insulation Resistance Test
5000M ohm each km
Conductor Resistance
2.4ohm/30m
Resistance Unbalance
Max. 4%
Capacitance Unbalance
Max. 99pF/30m
Mutual Capacitance
Max. 5600 pF/100m
Crack Test
Cold bend No crack (@-20℃x4hrs);Hot impact NO Crack(@150℃x4hrs)



40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 040G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 140G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 2



2.Packing & Shipping
1) Packing Lengths: 100/roll, 200m/roll, 300m/roll, 305m/roll, 500m woden reel, 1000m wooden reel
2) Inner Packing: Wooden reel, plastic reel, and paper reel
3) Outer Packing: Carton box, pull out box, pallet available
4) Other packing available according to clients' request
5) Usually we deliver our products by SEA. Other delivery methods are available upon request from clients.



40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 3



3.Our service
1) Quick Response -- All inquiries will be replied within 24 hours.
Professional Quotation -- All pricing will be quote according to customers' detailed specifications & requirements.
2) OEM & ODM Service -- Can print your own brand on the cable printing with foot or meter marking. -- Make customized designs for stickers, drums, outer cartons, etc.
3) Stable Quality -- All materials and products passed restrict QC procedures, compliant with international standards.
4) Fast Delivery -- LCL orders, 15 Days after confirmation; FCL orders, 20 days after confirmation.
5) Good After-sales Service -- We chose the fastest vessel to POD for delivery our goods to clients, -- All Documents will be issued according to clients' instructions, to save troubles from local customs. -- Any complaint to quality or packing issued will be responded, and terminated with proper solutions for clients.





4.What is the process of an order?

Send your detailed request → Feedback with quotation → Confirm quotation and make payment → Make artwork for approval→Make mould→Mold testing→Making samples→Sample testing(Approval) →Mass production→Quality checking→Packing →Delivery →After Service→Repeat Order...

40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 4



5. Good after-Sale Service.

1) All products will have been strictly Quality Checked in house before packing.

2) All products will be well packed before shipping.

5. Faster delivery

Sample order in stock, and 3-7 days for bulk production.

6. Shipping:

We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Post.





6.FAQ

Q1: Are you a factory or trading company?
A1: We are a manufacturer.

Q2: Where is your factory located? How can I visit there?

A2:Our factory are located in dongguan city.

You can fly to Guangzhou international airport. And tell us your flight No. We will arrange to pick you up.

Q3: May I buy samples from you?

A3: Yes! You are welcome to place sample order to test our superior quality and services.

Q4: What is your Warranty?

A4: All the products will have 12 months Warranty

Q5:What payment method do you accept?

A5:T/T(Bank transfer), , Money Gram, Paypal, etc.

Q6: Can you put my brand name (logo) on these products?

A6: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.

Q7: May I know the status of my order?

A7: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.

Q8: What’s the leading time? (How long do you need to prepare my goods?

A8: Delivery (no more than 1000pcs) will be arranged within 3-7 days after payment, and arrive you within about 3-7 working days via international express.

Q9: How will you deliver my goods to me?

A9: Your purchases will be delivered by DHL, UPS, FedEx, TNT, EMS your door. Air Cargo and Sea Cargo, Direct line, Air Mail also be accepted according to clients' request.

Q10: Can you provide us more other products to us to help us to save more shipping costs?

A10: Yes. There’re kinds of HDMI Cables, VGA Cables, DVI Cables, Data USB cables, Display port on DB 9, DB 25, Aux Audio and video Cables, Cat network LAN Cables will be the main products line of Nengjie Factory. The OEM bulk order will be accept as well



40G 2000Mhz CAT8 CAT7E Ethernet LAN Cable Double Shielded FTP 5

Our Factory Are Professional Manufacturer In Producing Widely Product Range Cat5/Cat5e/Cat6/Cat6a/Cat7/Cat8

Utp/Ftp/Sftp/Stp Network Cable,

Power Cable,Coaxial Cable,

Telephone Cable Etc.



Welcome To Visit Our Factory !
